LOCTITE ECCOBOND 3593 30CC

Name: LOCTITE ECCOBOND 3593 30CC
Brand: LOCTITE
SKU: B43558

LOCTITE ECCOBOND 3593 30CC LOCTITE, SALDATURA - ACCESSORI, ADESIVI.

Quantità a stock: 0

Prezzo non aggiornato

Risorse

Documenti del prodotto B43558

TDS B43558Apri il documento

B43558

Approfondimento

Loctite Eccobond 3593 30cc

LOCTITE 3593 is a rapid curing, fast flowing, liquid epoxy designed for use as a capillary flow underfill for chip size packages. It is designed for production where process speed is a key concern. Its rheology is designed to allow it to penetrate gaps as small as 25 µm.

LOCTITE 3593 is easily dispensed, minimizes induced stress, provides improved temperature cycling performance and has excellent chemical resistance.

HANDLING INFORMATION

Receiving Cold Shipments:

All shipping boxes are packed with cold gel packs to maintain temperature below 8°C during transit

TYPICAL PROPERTIES OF UNCURED MATERIAL
Specific Gravity @ 25 °C    1.18
VOC, ASTM D 3960, g/l                                             <1
Moisture Content, ASTM D 4017, %                       <0.11
Total Volatile Content, ASTM D 2369, %                0.12
Filler Content, % 0
Viscosity, Cone & Plate, mPa·s (cP):
Temperature: 25 °C, Shear Rate: 5 s-1                 3,500 to 6,500LMS
Temperature: 25 °C, Shear Rate: 20 s-1 4,500 to 6,000
Capillary Flow Rate, seconds:
Flow time, 100 °C, glass to glass, 25 µm:

6.35 mm flow                                                               ≤10
12.7 mm flow                                                               ≤30LMS
25.4 mm flow                                                                ≤70
Pot life @ 22 °C, days                                                  7
Flash Point - See MSDS

HENKEL GARANTISCE, AL MOMENTO DELLA RICEZIONE AL NOSTRO MAGAZZINO, UNA VITA UTILE RIMANENTE DEL PRODOTTO PARI AL 50%. NORMALMENTE I PRODOTTI VENGONO SPEDITI CON UNA SHELF LIFE VICINA AL 75%.
